Product Series |
Models |
Adhesive Properties |
Thickness (μm) |
Peel Force(gf/25mm) |
Refractive index |
Transmittance T |
Haze |
Yellow Index(b*) |
Product Features |
|
OCA for Functional Films |
CR-733xML |
Slightly soft |
50-175 |
≥2000 |
1.47-1.49 |
≥90% |
≤0.4% |
0.2 |
Suitable for high-end series ITO bonding, polarizer bonding, and other optical component bonding. |
|
OCA for Functional Films |
CR-533xM |
Slightly hard |
100-150 |
≥2200 |
1.47-1.49 |
≥90% |
≤0.5% |
0.2 |
Suitable for ITO bonding, polarizer bonding, and other optical component bonding in high-end series of small to medium-sized applications. |
|
OCA for Low Impedance |
CR-733xHL |
Slightly hard |
50-175 |
≥2000 |
1.47-1.49 |
≥90% |
≤0.4% |
0.2 |
Suitable for large-size functional film bonding in nano silver film and metal grid applications. |
|
Full lamination OCA |
CR-934xGM |
Soft |
100-250 |
Before UV≥1000 |
1.47-1.49 |
≥90% |
≤0.5% |
≤0.5 |
Suitable for module lamination such as G+G, TP+LCM, CG+In-cell, CG+On-cell, etc. |
|
Full lamination OCA |
CR-934xM |
Soft |
100-250 |
Before UV≥1000 |
1.47-1.49 |
≥90% |
≤0.5% |
≤0.5 |
Suitable for flat display module lamination. |
|
OCA for Blind Hole Screen |
CR-910xS |
Soft |
100-250 |
UBefore UV≥1000 |
1.47-1.49 |
≥90% |
≤0.5% |
≤0.5 |
Suitable for blind hole screen bonding. |
|
OCA for Curved Screen |
CR-92xxH |
Soft |
100-250 |
Before UV≥1000 |
1.47-1.49 |
≥90% |
≤0.5% |
≤0.5 |
Suitable for rigid and curved screen bonding. |
|
OCA for Foldable Screen |
CR-7102F |
Soft |
50 |
≥1000 |
1.47-1.49 |
>90% |
<1% |
<0.5 |
Suitable for foldable screen bonding. |
|
OCA for Foldable Screen |
CR-7202F |
Soft |
50 |
≥1000 |
1.47-1.49 |
>90% |
<1% |
<0.5 |
Suitable for foldable screen bonding. |
|
Acrylic OCA |
CR-10XXA |
Soft |
250-500 |
≥1000 |
1.47-1.49 |
>90% |
<1% |
<0.4 |
Suitable for automotive display bonding. |
|
Silicone OCA |
CR-10XXS |
Soft |
250-500 |
≥500 |
1.47-1.49 |
≥90% |
≤0.5% |
≤0.5 |
Suitable for automotive display bonding. |
