Guangdong Kunpeng New Materials Co., Ltd.

Explore adhesive material applications in the Industrial Manufacturing

Application Scenarios - Clothing bags

From the product design and development stage to the large-scale production process, every link fully considers the stringent needs and unique characteristics of the home appliance industry to ensure that the bonding solutions provided can not only accurately adapt to various complex application scenarios.

SOLUTION CONSULTATION →

1 Temporary fixation of computer embroidery process 2 Leather sewing positioning 3 Temporary fixation of lining of luggage by sewing 4 Sticky hair in the garment industry

1 Temporary fixation of computer embroidery process

: ● Acrylic pressure-sensitive adhesive
● Acrylic foam
● Acrylic pressure-sensitive
● Release paper

: ● Acrylic pressure-sensitive adhesive
● Acrylic foam
● Acrylic pressure-sensitive
● Release paper

: ● Acrylic pressure-sensitive adhesive
● Acrylic foam
● Acrylic pressure-sensitive
● Release paper

: ● Acrylic pressure-sensitive adhesive
● Acrylic foam
● Acrylic pressure-sensitive
● Release paper

Product Features

● Has strong stickiness, is used in the computer embroidery industry, and can play a good role in pasting and fixing fabrics of different materials.

● Oil-adhesive acrylic series models are designed with no stickiness on both sides, high stickiness on the bottom plate to prevent tape slippage, and low stickiness on the embroidery cloth to facilitate repeated fixing operations. It is suitable for fabrics with higher requirements.

● Hot melt adhesive model, high cost performance, suitable for general cloth embroidery.

Products	Model	Adhesive	Thickness (μm)	Initial adhesion (mm)	Adhesion (N/24MM)	Holding power (hour)	Comment
Tissue tape	DS10B3	Oily acrylic glue	90-100	≤120	Inner surface ≥ 10	Inner surface ≥ 30	Sticking the bottom plate on the high-sticking surface and sticking the embroidery cloth on the low-sticking surfaces
Tissue tape	DS11D	Oily acrylic glue	90	≤70	Inner face ≥ 8	Inner surface ≥ 60	/
Tissue tape	DS22C	Hot melt adhesive	145/155	≤180	≥22/≥23	Summer ≥ 4	Good value for money

2 Leather sewing positioning

: ● Acrylic pressure-sensitive adhesive
● Acrylic foam
● Acrylic pressure-sensitive
● Release paper

: ● Acrylic pressure-sensitive adhesive
● Acrylic foam
● Acrylic pressure-sensitive
● Release paper

: ● Acrylic pressure-sensitive adhesive
● Acrylic foam
● Acrylic pressure-sensitive
● Release paper

: ● Acrylic pressure-sensitive adhesive
● Acrylic foam
● Acrylic pressure-sensitive
● Release paper

Product Features

● The product is developed for leather pasting, has the characteristics of high initial adhesion and good wettability, has good pasting effect on leather, and prevents displacement during sewing.

Products	Model	Adhesive	Thickness (μm)	Initial adhesion (mm)	Adhesion (N/24MM)	Holding power (hour)	Comment
Tissue tape	DS10B6#	Oily acrylic glue	70-120	≤100	≥9-14	≥60	Developed for leather pasting

3 Temporary fixation of lining of luggage by sewing

: ● Acrylic pressure-sensitive adhesive
● Acrylic foam
● Acrylic pressure-sensitive
● Release paper

: ● Acrylic pressure-sensitive adhesive
● Acrylic foam
● Acrylic pressure-sensitive
● Release paper

: ● Acrylic pressure-sensitive adhesive
● Acrylic foam
● Acrylic pressure-sensitive
● Release paper

: ● Acrylic pressure-sensitive adhesive
● Acrylic foam
● Acrylic pressure-sensitive
● Release paper

Product Features

● The utility model has the characteristics of strong stickiness, good adherence and the like, has good sticking effect on the box body and the lining cloth, and prevents the lining from falling off during sewing

Products	Model	Adhesive	Thickness (μm)	Initial adhesion (mm)	Adhesion (N/24MM)	Holding power (hour)	Comment
Tissue tape	DS10WW	Oily acrylic glue	80-150	≤150	≥14-21	≥60	The colloid is wet and has strong viscosity.
Tissue tape	DS18	Hot melt adhesive	60-160	Summer ≥ 100 Winter ≤ 120	Summer ≥ 12-15 Winter ≤ 8-21	Summer ≥ 2 Winter ≤ 0.8	Good value for money

4 Sticky hair in the garment industry

: ● Acrylic pressure-sensitive adhesive
● Acrylic foam
● Acrylic pressure-sensitive
● Release paper

: ● Acrylic pressure-sensitive adhesive
● Acrylic foam
● Acrylic pressure-sensitive
● Release paper

: ● Acrylic pressure-sensitive adhesive
● Acrylic foam
● Acrylic pressure-sensitive
● Release paper

: ● Acrylic pressure-sensitive adhesive
● Acrylic foam
● Acrylic pressure-sensitive
● Release paper

Product Features

● Adopt solvent-free hot melt adhesive, no residue

● It has good initial adhesion and can quickly take away the wool on the cloth to achieve the cleaning effect.

● Can be repeatedly used for sticking hairs.

Products	Model	Adhesive	Thickness (μm)	Initial adhesion (mm)	Adhesion (N/24MM)	Holding power (hour)	Comment
Kraft paper tape	KT11	Hot melt adhesive	130	Summer ≥ 100 Winter ≤ 150	Summer ≥ 22 Winter ≤ 20	Summer ≥ 3 Winter ≤ 1.5	Sticky hair in the garment industry
