Explore adhesive material applications in the transportation industry

Application Products - Rail Transit

From the product design and development stage to the large-scale production process, every link fully considers the stringent needs and unique characteristics of the home appliance industry to ensure that the bonding solutions provided can not only accurately adapt to various complex application scenarios.

SOLUTION CONSULTATION →

1 Fixation of carriage parts

: ● Acrylic pressure-sensitive adhesive
● Acrylic foam
● Acrylic pressure-sensitive
● Release paper

: ● Acrylic pressure-sensitive adhesive
● Acrylic foam
● Acrylic pressure-sensitive
● Release paper

: ● Acrylic pressure-sensitive adhesive
● Acrylic foam
● Acrylic pressure-sensitive
● Release paper

: ● Acrylic pressure-sensitive adhesive
● Acrylic foam
● Acrylic pressure-sensitive
● Release paper

Product Features

● High and low temperature resistance, adapt to different temperature and humidity environment changes

● It has anti-seismic and anti-jitter performance, taking into account the filling effect.

● Normal operation in low temperature environment (0 ° C) meets EU ROHS2.0 environmental protection requirements

Application scenario

● It is suitable for the fixation of carriage parts, even in the case of low temperature in winter, it can also be firmly bonded to ensure the safety during transportation, assembly and use.

● Including but not limited to the following application scenarios:

● Adhesion of silencing cotton bearing part of carriage

● Bonding of trailer stands

● Bonding of truck panels

● Metal parts are bonded

Products	Model	Color	Thickness (μm)	Adhesion to steel plate (180 ° peel) 72h(N/25mm)	Static shear force *(24mm24mm)23℃, 1000g(min)**	Dynamic shear force *(24mm24mm) 72h(N)**	Annular initial adhesion *(24mm24mm) (N)**	Temperature resistance	Structure	Release layer material	Application
EPT	A7200WR-N	White	2000	62	>1440	665	28	-20℃-80℃	Single layer	PE red film	Adhesion of silencing cotton bearing part of carriage
EPT	A7110BR3-3D	Black	1100	50	>1440		80	-20℃-80℃	Three floors	PE red film	Bonding of trailer stands
EPT	A7110F-1D	Grey	1100	>45	>1440	>400	>45	-20℃-80℃	Three floors	Release paper	Bonding of truck panels
EPT	A7100WR	White	1000	58	>1440	754	50	-20℃-80℃	Single layer	PE red film	Metal parts are bonded
