| Model | Single/Double Sided | Thickness (mm) |
Conductive substrate | 180 ° peel force (N/25mm) |
X-Y horizontal resistance (Ω/□) |
Vertical resistance in Z direction (Ω/inch^2) |
Room temperature retention (Min) |
| EM5101-50 | Single-sided | 0.05 | Conductive woven cloth | ≥10 | ＜0.1 | ＜0.05 | ＞1440 |
| EM5101-120 | Single-sided | 0.12 | Conductive woven cloth | ≥12 | ＜0.2 | ＜0.05 | ＞1440 |
| EM6201-30 | Two-sided | 0.03 | Conductive woven cloth | A&B≥10 | ＜0.1 | ＜0.05 | ＞1440 |
| EM6201-50 | Two-sided | 0.05 | Conductive woven cloth | A&B≥12 | ＜0.1 | ＜0.05 | ＞1440 |
| EM6201-100 | Two-sided | 0.1 | Conductive woven cloth | A&B≥15 | ＜0.2 | ＜0.05 | ＞1440 |
| EM6201-200 | Two-sided | 0.2 | Conductive woven cloth | A&B≥18 | ＜0.2 | ＜0.05 | ＞1440 |
