| Model | Single/Double Sided | Thickness (mm) |
Conductive substrate | 180 ° peel force (N/25mm) |
X-Y horizontal resistance (Ω/□) |
Vertical resistance in Z direction (Ω/inch^2) |
Room temperature retention (Min) |
Product features |
| EM8301-20 | Two-sided | 0.02 | Conductive non-woven fabric | A&B≥8 | ＜0.2 | ＜0.02 | ＞1440 | Ultra-thin thickness |
| EM8301-30 | Two-sided | 0.03 | Conductive non-woven fabric | A&B≥10 | ＜0.1 | ＜0.02 | ＞1440 | Ultra-thin thickness |
| EM6301-50 | Two-sided | 0.05 | Conductive non-woven fabric | A&B≥12 | ＜0.2 | ＜0.05 | ＞1440 | The compliance is good |
| EM6301-100 | Two-sided | 0.1 | Conductive non-woven fabric | A&B≥15 | ＜0.2 | ＜0.08 | ＞1440 | The compliance is good |
